Rockwell Automation Publication 750-TG100B-EN-P - June 2019 113
Frame 7 Components Chapter 6
Power Module
Replacement
Replace the power module with the appropriate kit catalog number:
• 20-750-MI4-CnnnDnnn
• 20-750-MI4-EnnnFnnn
Equipment is available that is designed to help you safely handle the power
modules. The following equipment is recommended:
• PowerFlex 750-Series module service cart, catalog number
20-750-MCART1, publication 750-IN105
.
• PowerFlex 750TM power and LCL filter module storage hardware,
catalog number 20-750-MINV-ATIP, publication 750-IN106
.
• PowerFlex 755T power module service ramp, catalog number
20-750-MRAMP1, publication 750-IN108
.
Remove the Power Module from the Enclosure
Follow these steps to remove the power module from the enclosure.
1. Review the Product Advisories on page 14
.
2. Remove power from the system. See Remove Power from the System on
page 15
.
3. Open the enclosure door.
4. Remove the protective guard. See Remove the Protective Guard on page
110
.
IMPORTANT The service ramp is used only with power module when the cabinet is
mounted directly to the floor. Do not use the ramp to remove LCL filter
modules from the cabinet. Review service ramp instructions before using.
ATTENTION: IGBT power and LCL filter modules have a high center of gravity
and a tip-over hazard exists. To guard against death, serious personal injury, or
equipment damage, do not subject the module to high rates of acceleration or
deceleration while transporting. Do not push or pull above the points that are
indicated on the module.
