252 Rockwell Automation Publication 750-TG100B-EN-P - June 2019
Chapter 9 Power Bay Components
Install the Power Interface Circuit Board
Install the power interface circuit board in the reverse order of removal.
Balance Resistors
Replacement
Replace the power module balance resistors with the appropriate kit catalog
number:
• SK-RM-INVBR1-F8M (400/480V)
• SK-RM-INVBR2-F8M (600/690V)
Remove the Balance Resistors
Follow these steps to remove and replace the balance resistors.
1. Review the Product Advisories on page 14
.
2. Remove power from the system. See Remove Power from the System on
page 15
.
3. Open the corresponding power bay enclosure door.
4. Remove the power module from the enclosure. See Power Module
Replacement on page 236
.
