186 Rockwell Automation Publication 750-TG100B-EN-P - June 2019

Chapter 8 Input Bay Components

Install the Guards

Install the guards in the reverse order of removal.

AC Precharge Control

Circuit Board Replacement

Replace the AC precharge control circuit board with kit catalog numbers

20-750-MACPC1-CD and 20-750-MACPC1-EF.

Remove the AC Precharge Control Circuit Board

Follow these steps to remove and replace the AC precharge control circuit board.

1. Review the Product Advisories on page 14

2. Remove power from the system. See Remove Power from the System on

page 15

3. Open the input bay enclosure door.

4. Remove the guard from the enclosure. See Guard Removal on page 183
