98 Rockwell Automation Publication 750-TG100B-EN-P - June 2019
Chapter 6 Frame 7 Components
IP54 Exhaust Vent Filters
Replacement
The frame 7 IP54 exhaust vent requires four filters. Replace the IP54 exhaust
vent filters with two kits of catalog number SK-RM-PBFAN-54FLTR1.
See IP54 Exhaust Vent Filters Replacement on page 211
.
IP54, 800 mm Wide Door
Vent Filters Replacement
Replace the IP54, 800 mm wide door vent filters with kit catalog number
SK-RM-PB8DR-54FLTR1.
See IP54, 800/1000 mm Wide Door Vent Filters Replacement on page 180
.
IP21, 800 mm Wide Door
Vent Filter Replacement
Replace the IP21, 800 mm wide door vent filters with kit catalog number
SK-RM-PB8DR-21FLTR1.
See IP21, 800/1000 mm Wide Door Vent Filter Replacement on page 181
.
Control Pod Cover Removal
You must remove the control pod cover to access other components inside the
pod.
Remove the Control Pod Cover
Follow these steps to remove the control pod cover.
1. Review the Product Advisories on page 14
.
2. Remove power from the system. See Remove Power from the System on
page 15
.
3. Open the enclosure door.
To Next Page
