194 Rockwell Automation Publication 750-TG100B-EN-P - June 2019
Chapter 8 Input Bay Components
240V Power Distribution
Fuse (FH2) Replacement
Replace the 240V power distribution fuse (labeled FH2) with the appropriate kit
catalog number that is identified in Ta bl e 1 5
.
Remove the 240V Power Distribution Fuse
Fuse holder (labeled FH2) is on the control panel in the input bay. Follow these
steps to remove and replace the 240V power distribution fuse.
1. Review the Product Advisories on page 14
.
2. Remove power from the system. See Remove Power from the System on
page 15
.
3. Open the input bay enclosure door.
4. Remove the guard from the enclosure. See Guard Removal on page 183
.
Table 15 - 240V Power Distribution Fuse (FH2) Kit Ratings
Frame Size Voltage Class IP Rating Fuse Kit Cat. No. Fuse Amp Rating
8 400V/480V/600V IP21 SK-RM-IBFH2-FUSE2A-F8 15
690V SK-RM-IBFH2-FUSE2B-F8 16
400V/480V/600V IP54 SK-RM-IBFH2-FUSE2C-F8 20
690V SK-RM-IBFH2-FUSE2D-F8 20
9 400V/480V/600V IP21 SK-RM-IBFH2-FUSE2E-F9 25
690V SK-RM-IBFH2-FUSE2F-F9 25
400V/480V/600V IP54 SK-RM-IBFH2-FUSE2G-F9 35
690V SK-RM-IBFH2-FUSE2H-F9 40
10 400V/480V/600V IP21 SK-RM-IBFH2-FUSE2G-F9 35
690V SK-RM-IBFH2-FUSE2H-F9 40
400V/480V/600V IP54 SK-RM-IBFH2-FUSE2I-F10 60
690V SK-RM-IBFH2-FUSE2J-F10 63
11 400V/480V/600V IP21 SK-RM-IBFH2-FUSE2K-F11 45
690V SK-RM-IBFH2-FUSE2L-F11 50
400V/480V/600V IP54 SK-RM-IBFH2-FUSE2M-F11 70
690V SK-RM-IBFH2-FUSE2N-F11 80
12 400V/480V/600V IP21 SK-RM-IBFH2-FUSE2I-F10 60
690V SK-RM-IBFH2-FUSE2J-F10 63
400V/480V/600V IP54 SK-RM-IBFH2-FUSE2O-F12 70
690V SK-RM-IBFH2-FUSE2P-F12 80
