146 Rockwell Automation Publication 750-TG100B-EN-P - June 2019

Chapter 7 Control Bay and Control Pod Components

Control Pod Cover Removal

You must remove the control pod cover to access other components inside the

pod.

Remove the Control Pod Cover

Follow these steps to remove the control pod cover.

1. Review the Product Advisories on page 14

2. Remove power from the system. See Remove Power from the System on

page 15

3. Open the control bay enclosure door.
