Rockwell Automation PowerFlex 755TL User Manual

202 Rockwell Automation Publication 750-TG100B-EN-P - June 2019
Chapter 9 Power Bay Components
Power Module
(1)
20-750-MI1-CnnnDnnn
20-750-MI1-EnnnFnnn
20-750-MI2-CnnnDnnn
20-750-MI2-EnnnFnnn
20-750-MI3-CnnnDnnn
20-750-MI3-EnnnFnnn
––See page 236
DC Link Fuses SK-RM-DCFUSE1-F8 (400V/480V)
SK-RM-DCFUSE2-F8 (600V/690V)
See Figure 17 on page 205 9See page 241
Power Module Power Jumper (P5/P6) SK-RM-INV-JMPR-F8 See Figure 18 on page 206 10 See page 243
Power Layer Interface Circuit Board SK-RM-PLI1-F8 11 See page 249
Power Interface Circuit Board
(2)
SK-RM-PIB1-CnnnDnnn
SK-RM-PIB1-EnnnFnnn
SK-RM-PIB2-CnnnDnnn
SK-RM-PIB2-EnnnFnnn
SK-RM-PIB3-CnnnDnnn
SK-RM-PIB3-EnnnFnnn
12 See page 250
Balance Resistors SK-RM-INVBR1-F8M (400/480V)
SK-RM-INVBR2-F8M (600/690V)
See Figure 19 on page 207 13 See page 252
Current Sensor SK-RM-INVCS1-F8M (622 A)
SK-RM-INVCS2-F8M (1000 A)
14 See page 255
LCL Filter Module Kits
LCL Filter Module
(3)
20-750-ML1-CnnnDnnn
20-750-ML1-EnnnFnnn
See Figure 20 on page 208 –See page 257
AC Input Link Fuses SK-RM-ACFUSE1-F8
(400/480V, 600V/690V)
SK-RM-ACFUSE2-F8
(400/480V, 600V/690V)
SK-RM-ACFUSE3-F9
(400/480V)
SK-RM-ACFUSE4-F9
(400/480V)
SK-RM-ACFUSE5-F8
(600V/690V)
SK-RM-ACFUSE6-F9
(600V/690V)
15 See page 262
Capacitor Canister SK-RM-LCLCP1-F8M (30 µF)
SK-RM-LCLCP2-F8M (41 µF)
SK-RM-LCLCP3-F8M (62 µF)
SK-RM-LCLCP4-F8M (80 µF)
16 See page 264
AC Common Mode Filter Board SK-RM-EMCFB1 17 See page 268
Current Sense Board SK-RM-CSB1-700 (700 A)
SK-RM-CSB1-525 (525 A)
SK-RM-CSB1-350 (350 A)
SK-RM-CSB1-263 (263 A)
18 See page 270
Power and LCL Filter Module Kits
Table 19 - Power Bay Replacement Kits (Continued)
Description Catalog Number Identification Identification No. Replacement Instructions
