Rockwell Automation Publication 750-TG100B-EN-P - June 2019 285
Wire Entry/Exit Bay Components Chapter 10
IP54/IP21, 400 mm Wide
Door Vent Filters
Replacement
Replace the IP54/IP21, 400 mm wide door vent filters with kit catalog number
SK-RM-IB4DR-FLTR1.
See IP54/IP21, 400/600 mm Wide Door Vent Filters Replacement on page 179
.
IP54/IP21, 800 mm Wide
Door Vent Filters
Replacement
Replace the IP54/IP21, 800 mm wide door vent filters with kit catalog number
SK-RM-IB4DR-FLTR1.
See IP54, 800/1000 mm Wide Door Vent Filters Replacement on page 180
.
IP54/IP21, 400/800 mm
Wide Door Vent Fan and
Filter Assembly
Replacement
Replace the IP54/IP21, 400 mm or 800 mm wide door vent fan and filter
assembly with the appropriate kit catalog numbers:
• 400 mm, SK-RM-WBDR-FANFLR1
• 800 mm, SK-RM-WBDR-FANFLR2
Remove the IP54/IP21, 400/800 mm Wide Door Vent Fan and Filter
Assembly
Follow these steps to remove the IP54/IP21, 400/800 mm wide door vent fan,
and filter assembly.
1. Review the Product Advisories on page 14
.
2. Remove power from the system. See Remove Power from the System on
page 15
.
3. Open the wire bay enclosure door.
To Next Page
