Rockwell Automation Publication 750-TG100B-EN-P - June 2019 139
Chapter 7
Control Bay and Control Pod Components
This chapter provides detailed instructions for how to remove and replace
control bay and control pod components.
Control Bay and Control
Pod Kits
Tab le 11 lists the replacement kits available for the control bay and control pod
(frames 8…15).
Table 11 - Control Bay/Control Pod Replacement Kits
Description Catalog Number Identification Identification No. Replacement Instructions
Ventilation Components
IP21/IP54 Roof Vent Filter SK-RM-IBFAN-54FLTR1 See Figure 8
on page 140 1See page 142
IP21/IP54 Roof Vent Fan SK-RM-IBFAN1-F8 2 See page 143
IP21/IP54, 300 mm Wide Door Vent Filter SK-RM-CB3DR-FLTR1 3 See page 145
Control Pod Components
Fiber Transceiver Circuit Board 20-750-MFTB1-F8 See Figure 9 on page 141 4See page 148
Regenerative/Low Harmonic/Inverter
Main Control Circuit Board
SK-RM-MCB1-PF755 5 See page 152
Control Pod Backplane Circuit Board SK-RM-PODBP1 6 See page 155
Fiber-optic Interface Circuit Board,
Regenerative and Low Harmonic
SK-RM-FIB1-F8 7 See page 157
Fiber-optic Interface Circuit Board, Low
Harmonic
SK-RM-FIB2-F8 7 See page 157
Control Pod Fan Assembly SK-RM-PODFAN1-F8 8 See page 164
Control Pod Assembly, Regenerative and
Low Harmonic
20-750-MCPOD1-F8M – See page 166
Control Pod Assembly, Low Harmonic 20-750-MCPOD2-F8M – See page 166
Control Power Components
(1)
240V Power Distribution Fuse (FH2) SK-RM-IBFH2-FUSE2x-Fn See Figure 14 on page 178 13 See page 194
Roof Fan 240V Control Power Fuse (FH3) SK-RM-IBFH3-FUSE3x-Fn 14 See page 195
(1) These components are contained in the control bay for frame 8 and 9 drives and bus supplies. Removal procedures are included in Chapter 6 - Power Bay Components.
