Rockwell Automation Publication 750-TG100B-EN-P - June 2019 287

Wire Entry/Exit Bay Components Chapter 10

Thermal Switch

Replacement

Replace the thermal switch with kit catalog number SK-RM-THRMSW-WB.

Remove the Thermal Switch

Follow these steps to remove the thermal switch.

1. Review the Product Advisories on page 14

2. Remove power from the system. See Remove Power from the System on

page 15

3. Open the wire bay enclosure door.
