Rockwell Automation Publication 750-TG100B-EN-P - June 2019 65

Frame 5 Components Chapter 4

5. Remove the six M4 x 10 mm torx screws that secure the fan power supply

circuit board to the bracket and remove the board.

Install the Fan Power Supply Circuit Board

Install the fan power supply circuit board in the reverse order of removal.

M4 x 10 mm

T20

2.0 N•m (18.0 lb•in)
