Rockwell Automation Publication 750-TG100B-EN-P - June 2019 289

Wire Entry/Exit Bay Components Chapter 10

6. Disconnect the wires from the two terminals on the thermal switch.

Install the Thermal Switch

Install the thermal switch in the reverse order of removal.

M6 x 25 mm

T30

4.8 N•m (42 lb•in)
