222 Rockwell Automation Publication 750-TG100B-EN-P - June 2019
Chapter 9 Power Bay Components
Install the IP21, 400/600 mm Wide Door Vent Filter
Follow theses steps to install the IP21, 400/600 mm wide door vent filter.
1. Place the slots on the cassette cover on the tabs on the door vent chassis.
2. Insert the filter in the cassette chassis on the door and close and secure the
cassette cover to the door.
IP54, 800 mm Wide Door
Vent Filters Replacement
Replace the IP54, 800 mm wide door vent filters with kit catalog number
SK-RM-PB8DR-54FLTR1.
See IP54, 800/1000 mm Wide Door Vent Filters Replacement on page 180
.
IP21, 800 mm Wide Door
Vent Filter Replacement
Replace the IP21, 800 mm wide door vent filters with kit catalog number
SK-RM-PB8DR-21FLTR1.
See IP21, 800/1000 mm Wide Door Vent Filter Replacement on page 181
.
DC Precharge Module
Disconnect Handle and
Shaft Replacement
Replace the DC precharge module disconnect handle and shaft with kit catalog
number SK-RM-DCPC-HNDL.
Remove the DC Precharge Module Disconnect Handle and Shaft
Follow these steps to remove and replace the DC precharge module disconnect
handle and shaft.
1. Review the Product Advisories on page 14
.
2. Remove power from the system. See Remove Power from the System on
page 15
.
3. Open the corresponding power bay enclosure door.
IMPORTANT Verify that the weep holes on the metal mesh filter are at the bottom of the
filter when installed.
