Chapter 8
Input Bay Components
This chapter provides detailed instructions for how to remove and replace input
bay components.
Input Bay Kits
Tab le 13 lists the replacement kits available for input bay (frames 8…15).
Table 13 - Input Bay Replacement Kits
Description Catalog Number Identification Identification No. Replacement Instructions
Ventilation Components
IP21/IP54 Roof Vent Filter SK-RM-IBFAN-54FLTR1 See Figure 10 on page 174 1See page 179
IP54/IP21 Roof Vent Fan SK-RM-IBFAN1-F8 2 See page 179
IP54/IP21 Door Vent Filter (400 mm) SK-RM-IB4DR-FLTR1 3 See page 179
IP54/IP21 Door Vent Filter (600 mm) SK-RM-IB6DR-FLTR1 3 See page 179
IP54 Door Vent Filter (1000 mm) SK-RM-PB8DR-54FLTR1 See Figure 11 on page 175 4See page 180
IP21 Door Vent Filter (1000 mm) SK-RM-PB8DR-21FLTR1 5 See page 181
IP54/IP21 Door Vent Fan (1000 mm) SK-RM-IBDR-FAN1 6 See page 182
AC Precharge Components
AC Precharge Control Circuit Board 20-750-MACPC1-CD (400/480V)
20-750-MACPC1-EF (600/690V)
Frame 8 and 9, see Figure 12 on
page 176
Frame 10…12, see Figure 13 on
page 177
7See page 186
AC Precharge Control Circuit Board Fuses
(FH1)
SK-RM-IBCB-FUSE1A-F8
SK-RM-IBCB-FUSE1B-F9
8See page 192
AC Precharge Time Delay Relay 20-750-MACPC-TDR 9 See page 189
AC Precharge TVSS Module 20-750-MACP-xx-TVSS 10 See page 190
Control Transformer Fuses (FH4…FH7) SK-RM-IBFH4-FUSE4x-Fn 11 See page 197
AC Precharge Fused Disconnect (FD1)
Fuses
SK-RM-IBD-FUSEx-Fn 12 See page 199
AC Precharge Control Transformers – – – See page 200
Control Power Components
240V Power Distribution Fuse (FH2) SK-RM-IBFH2-FUSE2x-Fn Frame 8 and 9, seeFigure 14
on
page 178
Frame 10…12, see Figure 13 on
page 177
13 See page 194
Roof Fan 240V Control Power Fuse (FH3) SK-RM-IBFH3-FUSE3x-Fn 14 See page 195
