120
Detailed Settings for Each Function ([EDIT] Button)
A single, individual file containing a collection of 100 Setups
registered to the RD-700GX is called a “Setup File.”
This Setup file can be saved in the RD-700GX’s internal
memory or on USB memory (sold separately) connected to the
USB MEMORY connector.
If you want to save the changed settings of a
system parameter (p. 122), memorize settings by
pressing the [F1 (WRITE)] button, then save an
Setup file.
1.
Press the [EDIT] button, getting the indicator to
light.
The Edit Menu screen appears.
2.
Press the Cursor [ ] [ ] buttons to select
“5.File,” then press the [ENTER] button.
The Edit screen appears.
3.
Press the Cursor [ ] button to select “0. SAVE
SETUP File,” then press the [ENTER] button.
The following screen appears.
fig.05-14g
4.
Press the [F1 (MEDIA)] button to select the save
destination for the Setup file.
Detailed Settings of Compressor
Parameter
Value Description
Split Freq L
200, 250, 315,
400, 500, 630,
800 [Hz]
This sets the frequency
separating the low-
frequency range (LOW)
and midrange (MID).
Split Freq H
2000, 2500, 3150,
4000, 5000, 6300,
8000 [Hz]
This sets the frequency
separating the high-
frequency range (HIGH)
and midrange (MID).
Level
0–24dB
(1dB/1Step)
Output Level
Attack Time
0–100ms
This sets the time it takes
until the level is
compressed after the
input exceeds the
THRESHOLD.
Release
Time
50–5000ms
This sets the time it takes
for the compression to
be released after the
input falls below the
THRESHOLD.
Threshold
-36dB–0dB
(1dB/1step)
This sets the level at
which compression
begins.
Ratio
1:1.0, 1:1.1, 1:1.2.
1:1.4, 1:1.6, 1:1.8,
1:2.0, 1:2.5, 1:3.2,
1:4.0, 1:5.6, 1:8.0,
1:16, 1:INF
Compression Ratio
File Management (File)
Saving a Setup File (Save SETUP File)
RD-700GX_e.book 120 ページ ２００８年２月１３日 水曜日 午後５時４９分
To Next Page
