99
Using the RD-700GX As a Master Keyboard
To switch the tones of an external MIDI device, the program number and the MSB/LSB
of the Bank Select message are entered as numerical values on the RD-700GX.
1.
Press the [EXTERNAL/INTERNAL] button so the “EXTERNAL” indicator is lit.
The EXTERNAL screen appears.
If “MSB” doesn’t appear on screen, press the Cursor [ ] [ ] buttons several times to display the
following screen.
fig.Q3-07g
When Rec Mode is set to ON in the Utility Rec Setting in Edit mode, the EXTERNAL
screen as shown above is not displayed. Set Rec Mode to OFF when setting the MIDI
Transmit channel (p. 138).
2.
Use the Cursor [ ] [ ] [ ] [ ] buttons to move the cursor, and use the [DEC] [INC]
buttons or the VALUE dial to set the MSB, LSB, and PC for each zone.
Pressing the [DEC] [INC] buttons simultaneously switches the settings value to “- - - (OFF).”
When this setting is “- - - (OFF),” bank select messages will not be transmitted.
If the external MIDI sound generator transmits a Program number or a Bank number
for which no Tone has been assigned, an alternate Tone may be selected, or in some
cases, there may be no sound played. If you do not want to transmit the Program
number or Bank Select, use the procedure described above to set the PC/MSB/LSB to
“- - - (OFF).”
If this is set to “- - -,” the sound selection data will not be transmitted when you switch
Setups.
Selecting Sounds on an External MIDI Device (MSB/LSB/PC)
Parameter
Settings
MSB (Bank Select MSB: CC 00)
0–127, - - - (OFF)
LSB (Bank Select LSB: CC 32)
0–127, - - - (OFF)
PC (Program Change)
0–127, - - - (OFF)
NOTE
NOTE
RD-700GX_e.book 99 ページ ２００８年２月１３日 水曜日 午後５時４９分
