Roland RD-700GX User Manual

156
Effect/Parameter List
09: HUMANIZER
Adds a vowel character to the sound, making it similar to a
human voice.
10: SP.SIMULATR
(SPEAKER SIMULATOR)
Simulates the speaker type and mic settings used to record the
speaker sound.
Specifications of each Speaker Type
The speaker column indicates the diameter of each speaker
unit (in inches) and the number of units.
11: PHASER
This is a stereo phaser. A phase-shifted sound is added to the
original sound and modulated.
12: STEP PHASER
The phaser effect will be varied gradually.
Assignable Parameters
MFX Control
Rate, Drive, Depth, Vowel1, Vowel2, Manual
Parameter
Value Description
Drive Sw
OFF, ON Turns Drive on/off.
Drive 0–127
Degree of distortion
Also changes the volume.
Vowel1 a, e, i, o, u
Selects the vowel.
Vowel2 a, e, i, o, u
Rate Mode Hz, note
When this is set to “note,” the effect is
synchronized with the tempo.
Rate (Hz) 0.05–10.00 Hz
Frequency at which the two vowels
switch (Hz)
Rate ( ) note (*1)
Frequency at which the two vowels
switch (note)
Depth 0–127 Effect depth
Input Sync Sw OFF, ON
Determines whether the LFO for
switching the vowels is reset by the
input signal (ON) or not (OFF).
Input Sync Thres 0–127 Volume level at which reset is applied
Manual 0–100
Point at which Vowel 1/2 switch
49 or less : Vowel 1 will have a longer
duration.
50 : Vowel 1 and 2 will be of equal
duration.
51 or more : Vowel 2 will have a
longer duration.
Low Gain -15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Pan L64–63R Stereo location of the output
Level 0–127 Output level
Assignable Parameters
MFX Control
Direct Level, Mic Level, Speaker
Parameter
Value Description
Speaker
(See the table.) Type of speaker
Mic Setting 1, 2, 3
Adjusts the location of the mic that is
recording the sound of the speaker.
This can be adjusted in three steps,
with the mic becoming more distant in
the order of 1, 2, and 3.
Mic Level 0–127 Volume of the microphone
Direct Level 0–127 Volume of the direct sound
Level 0–127 Output Level
Type
Cabinet Speaker Microphone
SMALL 1 small open-back enclosure 10 dynamic
SMALL 2 small open-back enclosure 10 dynamic
MIDDLE open back enclosure 12 x 1 dynamic
JC-120 open back enclosure 12 x 2 dynamic
BUILT-IN 1 open back enclosure 12 x 2 dynamic
BUILT-IN 2 open back enclosure 12 x 2 condenser
BUILT-IN 3
open back enclosure 12 x 2 condenser
BUILT-IN 4 open back enclosure 12 x 2 condenser
BUILT-IN 5 open back enclosure 12 x 2 condenser
BG STACK 1 sealed enclosure 12 x 2 condenser
BG STACK 2 large sealed enclosure 12 x 2 condenser
MS STACK 1 large sealed enclosure 12 x 4 condenser
MS STACK 2 large sealed enclosure 12 x 4 condenser
METAL STACK large double stack 12 x 4 condenser
2-STACK large double stack 12 x 4 condenser
3-STACK large triple stack 12 x 4 condenser
Assignable Parameters
MFX Control
Rate, Resonance, Manual, Mix
Parameter
Value Description
Mode
4-STAGE,
8-STAGE,
12-STAGE
Number of stages in the phaser
Manual 0–127
Adjusts the basic frequency from
which the sound will be modulated.
Rate Mode Hz, note
When this is set to “note,” the effect is
synchronized with the tempo.
Rate (Hz) 0.05–10.00 Hz Frequency of modulation (Hz)
Rate ( ) note (*1) Frequency of modulation (note)
Depth 0–127 Depth of modulation
Polarity
INVERSE,
SYNCHRO
Selects whether the left and right
phase of the modulation will be the
same or the opposite.
INVERSE : The left and right phase will
be opposite. When using a mono
source, this spreads the sound.
SYNCHRO : The left and right phase
will be the same. Select this when
inputting a stereo source.
Resonance 0–127 Amount of feedback
Cross Feedback -98– +98%
Adjusts the proportion of the phaser
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
Mix 0–127 Level of the phase-shifted sound
Low Gain -15– +15 dB Gain of the low range
High Gain -15– +15 dB Gain of the high range
Level 0–127 Output Level
Assignable Parameters
MFX Control
StepRate, Depth, Resonance, Manual, Mix
Parameter Value Description
Mode
4-STAGE,
8-STAGE,
12-STAGE
Number of stages in the phaser
Manual 0–127
Adjusts the basic frequency from
which the sound will be modulated.
Rate Mode Hz, note
When this is set to “note,” the effect is
synchronized with the tempo.
Rate (Hz) 0.05–10.00 Hz Frequency of modulation (Hz)
Rate ( ) note (*1) Frequency of modulation (note)
Depth 0–127 Depth of modulation
Type
Cabinet Speaker Microphone
RD-700GX_e.book 156 ページ ２００８年２月１３日 水曜日 午後５時４９分
