154
Effect/Parameter List
00: THRU
01: EQUALIZER
This is a four-band stereo equalizer (low, mid x 2, high).
02: SPECTRUM
This is a stereo spectrum. Spectrum is a type of filter which
modifies the timbre by boosting or cutting the level at specific
frequencies.
03: ISOLATOR
This is an equalizer which cuts the volume greatly, allowing
you to add a special effect to the sound by cutting the volume
in varying ranges.
04: LOW BOOST
Boosts the volume of the lower range, creating powerful lows.
05: SUPER FILTR (SUPER FILTER)
This is a filter with an extremely sharp slope. The cutoff
frequency can be varied cyclically.
Multi-Effects Parameter
Assignable Parameters
MFX Control
Low Gain, High Gain, Level
Parameter
Value Description
Low Freq
200, 400 Hz Frequency of the low range
Low Gain -15– +15 dB Gain of the low range
Mid1 Freq 200–8000 Hz Frequency of the middle range 1
Mid1 Gain -15– +15 dB Gain of the middle range 1
Mid1 Q
0.5, 1.0, 2.0,
4.0, 8.0
Width of the middle range 1
Set a higher value for Q to narrow the
range to be affected.
Mid2 Freq 200–8000 Hz Frequency of the middle range 2
Mid2 Gain -15– +15 dB Gain of the middle range 2
Mid2 Q
0.5, 1.0, 2.0,
4.0, 8.0
Width of the middle range 2
Set a higher value for Q to narrow the
range to be affected.
High Freq
2000, 4000,
8000 Hz
Frequency of the high range
High Gain -15– +15 dB Gain of the high range
Level 0–127 Output Level
Assignable Parameters
MFX Control
Level
Parameter
Value Description
Band1 (250Hz)
-15– +15 dB Gain of each frequency band
Band2 (500Hz)
Band3
(1000Hz)
Band4
(1250Hz)
Band5
(2000Hz)
Band6
(3150Hz)
Band7
(4000Hz)
Band8
(8000Hz)
Q
0.5, 1.0, 2.0,
4.0, 8.0
Simultaneously adjusts the width of the
adjusted ranges for all the frequency
bands.
Level 0–127 Output Level
Assignable Parameters
MFX Control
Boost/Cut Low, Boost/Cut Mid, Boost/Cut High
Parameter
Value Description
Boost/Cut Low
-60– +4 dB
These boost and cut each of the High,
Middle, and Low frequency ranges.
At -60 dB, the sound becomes
inaudible. 0 dB is equivalent to the
input level of the sound.
Boost/Cut Mid
Boost/Cut High
APhase Low Sw OFF, ON
Turns the Anti-Phase function on and
off for the Low frequency ranges.
When turned on, the counter-channel
of stereo sound is inverted and added
to the signal.
APhase Low Lev 0–127
Adjusts the level settings for the Low
frequency ranges.
Adjusting this level for certain
frequencies allows you to lend
emphasis to specific parts. (This is
effective only for stereo source.)
APhase Mid Sw OFF, ON Settings of the Anti-Phase function for
the Middle frequency ranges
The parameters are the same as for
the Low frequency ranges.
APhase Mid Lev 0–127
Low Boost Sw OFF, ON
Turns Low Booster on/off.
This emphasizes the bottom to create a
heavy bass sound.
Low Boost Level 0–127
Increasing this value gives you a
heavier low end.
Depending on the Isolator and filter
settings this effect may be hard to
distinguish.
Level 0–127 Output Level
Assignable Parameters
MFX Control
Boost Gain, Boost Freq
Parameter
Value Description
Boost Freq
50–125 Hz
Center frequency at which the lower
range will be boosted
Boost Gain 0– +12 dB
Amount by which the lower range will
be boosted
Boost Width
WIDE, MID,
NARROW
Width of the lower range that will be
boosted
Low Gain -15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Level 0–127 Output level
Assignable Parameters
MFX Control
Filter Cutoff, Filter Resonance, Rate, Depth
RD-700GX_e.book 154 ページ ２００８年２月１３日 水曜日 午後５時４９分
