Effect/Parameter List
These settings allow you to select the desired type of reverb,
and its characteristics.
0: OFF
Reverb is not used.
1: REVERB
Normal reverb
2: SRV ROOM
This simulates typical room acoustic reflections.
3: SRV HALL
This simulates typical concert hall acoustic reflections.
The parameters are the same as for “2: SRV_ROOM.”
4: SRV PLATE
This simulates a reverb plate, a popular type of artificial
reverb unit that derives its sound from the vibration of a
metallic plate.
The parameters are the same as for “2: SRV_ROOM.”
5: GM2 REVERB
GM2 Reverb
6: CATHEDRAL
Simulates the type of reverberation in churches and other such
spaces bounded by hard walls
Reverb Parameter
Parameter
Value Description
Type
ROOM1,
ROOM2,
STAGE1,
STAGE2,
HALL1,
HALL2,
DELAY,
PAN-DELAY
Type of reverb/delay
ROOM1 : short reverb with high
density
ROOM2 : short reverb with low density
STAGE1 : reverb with greater late
reverberation
STAGE2 : reverb with strong early
reflections
HALL1 : very clear-sounding reverb
HALL2 : rich reverb
DELAY : conventional delay effect
PAN-DELAY : delay effect with echoes
that pan left and right
Time 0–127
Time length of reverberation
(Type: ROOM1-HALL2)
Delay time
(Type: DELAY, PAN-DELAY)
HF Damp
200–8000 Hz,
BYPASS
Adjusts the frequency above which the
high-frequency content of the reverb
sound will be cut, or “damped.” If you
do not want to cut the high
frequencies, set this parameter to
BYPASS.
Delay Feedback 0–127
Adjusts the amount of delay feedback
when the Type setting is DELAY or
PAN-DELAY.
Level 0–127 Output level of reverberation
Parameter
Value Description
Pre Delay
0.0–100.0 ms
Adjusts the delay time from the direct
sound until the reverb sound is heard.
Time 0–127 Time length of reverberation
Size 1–8 Size of the simulated room or hall
High Cut
160–
12500 Hz,
BYPASS
Adjusts the frequency above which the
high-frequency content of the reverb
will be reduced. If you do not want to
reduce the high frequencies, set this
parameter to BYPASS.
Density 0–127 Density of reverb
Diffusion 0–127
Adjusts the change in the density of
the reverb over time. The higher the
value, the more the density increases
with time. (The effect of this setting is
most pronounced with long reverb
times.)
LF Damp Freq 50–4000 Hz
Adjusts the frequency below which the
low-frequency content of the reverb
sound will be reduced, or “damped.”
LF Damp Gain -36–0 dB
Adjusts the amount of damping
applied to the frequency range
selected with LF Damp. With a setting
of “0,” there will be no reduction of
the reverb’s low-frequency content.
HF DampFreq
4000–
12500 Hz
Adjusts the frequency above which the
high-frequency content of the reverb
sound will be reduced, or “damped.”
HF Damp Gain -36–0 dB
Adjusts the amount of damping
applied to the frequency range
selected with HF Damp. With a setting
of “0,” there will be no reduction of
the reverb’s high-frequency content.
Level 0–127 Output level of reverberation
Parameter
Value Description
Character
ROOM1,
ROOM2,
ROOM3,
HALL1, HALL2,
PLATE, DELAY,
PAN-DELAY
Type of reverb
Pre-LPF 0–7
Cuts the high frequency range of the
sound coming into the reverb.
Higher values will cut more of the high
frequencies.
Level 0–127 Output level of reverberation
Time 0–127 Time length of reverberation
Delay Feedback 0–127
Adjusts the amount of the delay sound
that is fed back into the effect when the
Reverb Character setting is 6 or 7.
Parameter Value Description
Pre-LPF
0–7
Cuts the high frequency range of the
sound coming into the reverb.
Higher values will cut more of the high
frequencies.
Level 0–127 Output level of reverberation
Time 0–127 Time length of reverberation
Parameter
Value Description
