39
Performance
Up to two optional wave expansion boards (SRX series) can be installed into the RD-
700GX.
Use the following procedure when selecting tones stored on an wave expansion board.
For instructions on installing the Expansion Board, refer to “Installing the Wave
Expansion Board” (p. 143).
fig.Q1-08p
1.
Press the ONE TOUCH [PIANO] button or ONE TOUCH [E. PIANO] button.
This selects a single tone to be played over the entire keyboard.
2.
Press the EXPANSION [A] button or [B] button to make its indicator light.
fig.Q1-09g
If you hold down the EXPANSION [A] button or [B] button for several seconds, the name of the
installed wave expansion board appears in the display (p. 143).
3.
Press the [NUM LOCK] button to turn on the button indicator.
4.
Use the [DEC] [INC] buttons, or press any of the TONE SELECT buttons to select the Tone.
When using the TONE SELECT buttons to input Tone numbers, press the [ENTER] button afterwards
to set the number.
You can also select the tone number by turning the VALUE dial.
5.
Play the keyboard, and you will hear the selected tone.
For more on the wave expansion board tone lists, refer to “Patch List” (for RD-700)
and “Rhythm Set List” (for RD-700) in the SRX Series Owner’s Manuals. However,
some of the tone names may be displayed differently on the RD-700GX. Refer to
“Wave Expansion Board Tone Name Correspondence Table” (p. 40).
In the case of tones from a wave expansion board (SRX series), settings you’ve edited
in TONE INFO cannot be saved in the TONE INFO screen. If you want to save these
settings, you must store them in a Setup (p. 67).
Selecting Wave Expansion Board Tones
NOTE
RD-700GX_e.book 39 ページ ２００８年２月１３日 水曜日 午後５時４９分
