GENERAL INFORMATION 1-9
CHASSIS
Front suspension .......................................................... Telescopic, coil spring, oil damped
Rear suspension ........................................................... Swingarm, coil spring, oil damped
Front suspension stroke ............................................... 130 mm (5.1 in)
Rear wheel travel .......................................................... 123 mm (4.7 in)
Caster ........................................................................... 26°
Trail ................................................................................ 105 mm (4.1 in)
Steering angle .............................................................. 37° (right and left)
Turning radius ............................................................... 2.8 m (9.2 ft)
Front brake .................................................................... Disc brake, twin
Rear brake .................................................................... Disc brake
Front tire size ................................................................ 120/70 ZR17 (58 W), tubeless
Rear tire size ................................................................. 190/50 ZR17 (73 W), tubeless
ELECTRICAL
Ignition type .................................................................. Electronic ignition (Transistorized)
Ignition timing ................................................................ 7° B.T.D.C. at 1 100 r/min
Spark plug ..................................................................... NGK CR8EK DENSO U24ETR
Battery .......................................................................... 12 V 43.2 kC (12 Ah)/10 HR
Generator ...................................................................... Three-phase A.C. generator
Main fuse ...................................................................... 30 A
Fuse .............................................................................. 10/10/15/15/10/10 A
Headlight ....................................................................... 12 V 60/55 W (H4)
Position light .................................................................. 12 V 5 W ….. Except E-24
Turn signal light ............................................................. 12 V 21 W
Brake light/Taillight ........................................................ 12 V 21/5 W × 2
Speedometer light......................................................... LED
Tachometer light ........................................................... LED
Turn signal indicator light .............................................. LED
Neutral indicator light .................................................... LED
High beam indicator light .............................................. LED
Oil pressure indicator light ............................................ LED
Fuel injection warning light ........................................... LED
CAPACITIES
Fuel tank, including reserve ......................................... 22 L (5.8/4.8 US/Imp gal)
Engine oil, oil change ................................................... 4 200 ml (4.4/3.7 US/Imp qt)
with filter change ......................................... 4 800 ml (5.1/4.2 US/Imp qt)
overhaul ...................................................... 5 700 ml (6.0/5.0 US/Imp qt)
Front fork oil (each leg) ................................................. 648 ml (21.9/22.8 US/Imp oz)
These specifications are subject to change without notice.
