SERVICING INFORMATION 8-33
TIGHTENING TORQUE
ENGINE
ITEM N
.
m kgf
.
m lb-ft
Exhaust pipe bolt 23 2.3 16.5
Exhaust pipe connecting bolt 20 2.0 14.5
Muffler connecting bolt 24 2.4 17.5
Muffler mounting bolt 23 2.3 16.5
Speed sensor rotor bolt 20 2.0 14.5
Engine sprocket nut 115 11.5 83.0
Cylinder head cover bolt (M:8) 20 2.0 14.5
(M:7) 14 1.4 10.0
Spark plug 11 1.1 8.0
Cam chain guide bolt 10 1.0 7.3
Camshaft journal holder bolt 10 1.0 7.3
Cam chain tension adjuster cap bolt 35 3.5 25.5
Cam chain tension adjuster mounting bolt 10 1.0 7.3
Cylinder head bolt/nut (M:10) (Initial) 25 2.5 18.0
(Final) 37 3.7 27.0
(M:6) 10 1.0 7.3
PAIR reed valve cover bolt 10 1.0 7.3
Clutch cover bolt 11 1.1 8.0
Clutch sleeve hub nut 90 9.0 65.0
Clutch spring set bolt 10 1.0 7.3
Starter clutch bolt 25 2.5 18.0
Generator cover bolt 11 1.1 8.0
Generator rotor bolt 160 16.0 115.5
Generator stator set bolt 10 1.0 7.3
Gearshift cam stopper bolt 10 1.0 7.3
Gearshift cam stopper plate bolt 10 1.0 7.3
Oil pressure switch 14 1.4 10.0
Crankcase bolt (M:6) 11 1.1 8.0
(M:8) 26 2.6 19.0
(M:9) (Initial) 18 1.8 13.0
(Final) 32 3.2 23.0
Oil drain plug 23 2.3 16.5
Cylinder nut 10 1.0 7.3
Cam sprocket
bolt 25 2.5 18.0
Oil hose union bolt
(Crankcase – Cylinder head cover) 10 1.0 7.3
(Crankcase – Cylinder head) 20 2.0 14.5
CKP sensor
rotor bolt 25 2.5 18.0
CKP sensor
cover bolt
11 1.1 8.0
Oil gallery plug (Cylinder head cover) 14 1.4 10.0
(Cylinder head) 20 2.0 14.5
(Main gallery) 35 3.5 25.5
(Sub-gallery) 21 2.1 15.0
Oil check valve plug 35 3.5 25.5
Oil pipe bolt 10 1.0 7.3
