CHASSIS 6-13
REMOVAL AND DISASSEMBLY
• Remove the front wheel. (6-7)
• Disconnect the brake hoses.
• Remove the front fender and brake hose guides.
• Loosen the front fork upper clamp bolts 1.
NOTE:
Slightly loosen the front fork cap bolts
2 before loosening the
lower clamp bolts to facilitate later disassembly.
• Loosen the front fork lower clamp bolts.
NOTE:
Hold the front fork by the hand to prevent sliding out of the steer-
ing stem.
• Remove the protecter 3.
