10-8 GSX1400K4 (’04-MODEL)
ELECTRICAL
Unit: mm (in)
ITEM
STD/SPEC.
NOTE
Firing order 1·2·4·3
Spark plug
Type
NGK: CR8EK
DENSO: U24ETR
Gap
0.6 – 0.7
(0.024 – 0.028)
Spark performance Over 8 (0.3) at 1 atm.
CKP sensor resistance 134 – 202 Ω
CKP sensor peak voltage More than 2.7 V

+: Y

-: Bl
Ignition coil resistance
Primary 2 – 4 Ω
Terminal –
Terminal
Secondary 25 – 40 kΩ
Plug cap –
Plug cap
Ignition coil primary peak voltage
More than 150 V
No.1&4

+: W/Bl

-: O/W
No.2&3

+: B

-: O/W
Generator coil resistance 0.2 – 1.0 Ω
Generator no-load voltage
(When engine is cold)
More than 60 V (AC) at 5 000 r/min
Regulated voltage 14.0 – 15.5 V at 5 000 r/min
Starter relay resistance 3 – 5 Ω
GP switch voltage More than 0.6 V (From 1st to top without neutral)
Battery Type designa-
tion
FTX14-BS
Capacity 12 V 43.2 kC (12 Ah)/10 HR
Fuse size
Headlight
HI 10 A
LO 10 A
Signal 15 A
Ignition
* 10 A
Fuel 10 A
Fan 10 A
Main 30 A
