PERIODIC MAINTENANCE 2-25
CHASSIS BOLTS AND NUTS
Check that all chassis bolts and nuts are tightened to their specified torque. The locations of the following nuts
and bolts on the motorcycle.:2-26
Item N
.
m kgf
.
m Ib-ft
1 Steering stem head nut 65 6.5 47.0
2 Steering stem lock nut 80 8.0 58.0
3 Front fork upper clamp bolt 23 2.3 16.5
4 Front fork lower clamp bolt 23 2.3 16.5
5 Front axle 100 10.0 72.5
6 Front axle pinch bolt 23 2.3 16.5
7 Handlebar set bolt 23 2.3 16.5
8 Handlebar clamp bolt 95 9.5 68.5
9 Front brake master cylinder mounting bolt 10 1.0 7.0
0 Front brake caliper mounting bolt 26 2.6 19.0
A Brake hose union bolt (Front & Rear) 23 2.3 16.5
B Caliper air bleeder valve (Front & Rear) 8 0.8 6.0
C Brake disc bolt 23 2.3 16.5
D Rear brake caliper mounting bolt 26 2.6 20.0
E Rear brake master cylinder mounting bolt 10 1.0 7.3
F Rear brake master cylinder rod lock nut 18 1.8 13.0
G Front footrest bracket mounting bolt 26 2.6 19.0
H Swingarm pivot nut 100 10.0 72.5
I Torque link bolt and nut (Front) 28 2.8 20.0
J Torque link bolt and nut (Rear) 34 3.4 24.6
K Rear shock absorber (Upper) 23 2.3 16.5
L Rear shock absorber (Lower) 34 3.4 24.5
M Rear axle nut 100 10.0 72.5
N Rear sprocket nut 60 6.0 43.5
