GSX1400K4 (’04-MODEL) 10-9
WATTAGE
Unit: W
BRAKE + WHEEL
Unit: mm (in)
ITEM
STD/SPEC.
Headlight HI 60 W
LO 55 W
Parking or position light 5 W (Except for E-24)
Brake light/Taillight 21/5 W × 2
Turn signal light 21 W × 4
Speedometer light LED
Tachometer light LED
Turn signal indicator light LED
High beam indicator light LED
Neutral indicator light LED
FI indicator light LED
Oil pressure indicator light LED
ITEM
STD/SPEC.
LIMIT
Rear brake pedal height 35 – 45
(1.4 – 1.8)
—
Brake disc thickness
Front
4.8 – 5.2
(0.189 – 0.205)
4.5
(0.177)
Rear
5.3 – 5.7
(0.209 – 0.224)
5.0
(0.197)
Brake disc runout
—
0.30
(0.012)
Master cylinder bore
Front
15.870 – 15.913
(0.6248 – 0.6265)
—
Rear
12.700 – 12.743
(0.5000 – 0.5017)
—
Master cylinder piston diam.
Front
15.827 – 15.854
(0.6231 – 0.6242)
—
Rear
12.657 – 12.684
(0.4983 – 0.4994)
—
Brake caliper cylinder bore
Front
Leading
24.000 – 24.076
(0.9449 – 0.9479)
—
Trailing
27.000 – 27.076
(1.0630 – 1.0660)
—
Rear
38.180 – 38.230
(1.5031 – 1.5051)
—
Brake caliper piston diam.
Front
Leading
23.925 – 23.975
(0.9419 – 0.9439)
—
Trailing
26.920 – 26.970
(1.0598 – 1.0618)
—
Rear
38.115 – 38.148
(1.5006 – 1.5019)
—
Brake fluid type DOT 4 —
