8-22 SERVICING INFORMATION
Approx. 35Ëš
Approx. 14Ëš
Approx. 14Ëš
Approx. 35Ëš
Approx. 14Ëš
Approx. 28Ëš
Approx. 35Ëš
Approx. 14Ëš
Approx. 14Ëš
Approx. 14Ëš
Approx. 28Ëš
Approx.
21Ëš
Approx. 35Ëš
Approx. 7Ëš
Approx. 7Ëš
After touching the hose
union to the stopper,
tighten the union bolt.
After touching the hose
union to the stopper,
tighten the union bolt.
After touching the hose
union to the stopper,
tighten the union bolt.
After touching the hose
union to the stopper,
tighten the union bolt.
Throttle cable
Brake hose
No. 1
Right brake
No. 2
Left brake
hose No. 2
Clamp
Clamp
FWD
FRONT BRAKE HOSE ROUTING
