2-22 PERIODIC MAINTENANCE
REAR BRAKE
• Bleed air from the rear brake system as the same manner of
front brake.
NOTE:
The only difference between bleeding the front and rear brakes is
that the rear master cylinder is actuated by a pedal.
TIRES
TIRE TREAD CONDITION
Operating the motorcycle with excessively worn tires will decrease
riding stability and consequently invite a dangerous situation. It is
highly recommended to replace a tire when the remaining depth
of tire tread reaches the following specification.
\ 09900-20805: Tire depth gauge
Tire tread depth:
Service Limit: FRONT 1.6 mm (0.06 in)
REAR 2.0 mm (0.08 in)
• Close the air bleeder valve and disconnect the hose. Fill the
reservoir with brake fluid to the top of the inspection window.
" Air bleeder valve: 8 N
.
m (0.8 kgf
.
m, 6.0 Ib-ft)
Handle brake fluid with care: the fluid reacts chemically
with paint, plastics, rubber materials, etc.
To Next Page
