Suzuki GSX1400K4 2004 User Manual

CHASSIS 6-3
REMOVAL
SEAT
• Remove the seat with the ignition key.
FRAM COVERS
• Remove the seat. (Above)
• Remove the frame cover mounting secrews (left and right sides).
• Remove the frame covers by pulling on the hooked parts.
PILLION RIDER HANDLE
• Remove the pillion rider handle by removing the pillion rider
handle mounting bolts.
SEAT TAIL COVER
• Remove the seat. (Above)
• Remove the pillion rider handle. (Above)
• Remove the seat tail cover mounting screws.
: hooked part
