1.3 Assembly overview
1 - Glass panel for sliding/tilting
sunroof (single pane safety
glass)
❑ Removing and installing
⇒ page 157
❑ Height adjustment
⇒ page 158
❑ Checking parallel run‐
ning ⇒ page 159
❑ Adjusting parallel run‐
ning ⇒ page 160
2 - Boot
❑ Left and right.
❑ To cover guide plate.
3 - Bolt
❑ Qty. 3 on each side.
❑ Specified torque: 7 Nm
4 - Bolt
❑ Qty. 2 on each side.
❑ Specified torque: 1 Nm
❑ For attaching slide to
sliding headlining.
5 - Slide
❑ Qty. 2 on each side.
❑ For sliding headlining.
6 - Sliding headlining
❑ Removing and installing
⇒ page 161
7 - Carrier unit
❑ Removing and installing
⇒ page 165
❑ U-frame (with guide channels): Grease guide channels as required with special grease G 000 450 02
only. Otherwise correct operation cannot be guaranteed.
8 - Bolt
❑ Qty. 12.
❑ Specified torque: 8 Nm
❑ For attaching carrier unit to roof
9 - Bolt
❑ Qty. 3.
❑ Specified torque: 4 Nm
10 - Drive for sliding/tilting sunroof
❑ Removing and installing ⇒ page 162
❑ Adjusting ("0" position) ⇒ page 163 .
11 - Wind deflector
❑ Removing and installing ⇒ page 160
12 - Panel seal
❑ Renewing ⇒ page 160
Jetta 2011 ➤ , Jetta Hybrid 2013 ➤
General body repairs, exterior - Edition 08.2012
156 Rep. gr.60 - Sunroof
