5.4.2 Installing
Carry out following work:
Note
Check grommets -4- for damage and renew if necessary.
– Place trim -1- against B-pillar.
– Press trim securing pins -2- into grommets -4-.
– Insert clips -3- and press spreader pins -5- into clips
-arrow a-.
5.5 Side member extension “GLI”
Note
The removal and installation sequence is for the left side member
(sill) extension. The removal and installation of the right side
member (sill) extension is similar.
Jetta 2011 ➤ , Jetta Hybrid 2013 ➤
General body repairs, exterior - Edition 08.2012
282 Rep. gr.66 - Exterior equipment
