1.2 Assembly overview - front wheel housing liner
Note
♦ Minor differences may be encountered in respect of wheel housing liner, depending on vehicle model.
♦ Only the left side is shown. The right side is similar.
1 - Wheel housing liner
❑ Material PP/EPDM.
❑ Removing and installing
⇒ page 236
2 - Bolt
❑ Qty. 12.
❑ Specified torque: 2 Nm
3 - Expanding nut
❑ Qty. 6.
❑ Renew if damaged
1.3 Removing and installing front wheel
housing liner
Note
♦ The removal and installation sequence is only for the left wheel
housing liner. Removal and installation of the right wheel
housing liner are similar.
♦ The removal and installation procedures may have to be modi‐
fied slightly depending on model variants.
Jetta 2011 ➤ , Jetta Hybrid 2013 ➤
General body repairs, exterior - Edition 08.2012
236 Rep. gr.66 - Exterior equipment
