3-14
IM 04L51B01-01EN
Saving EventData
Unsaved event data stored in the internal memory is saved to the SD memory card.
Procedure
1
On the Operation tab, click Eventsave.
An Event save dialog box appears.
2
Click Save event data.
The event data is saved.
Aborting Data Saving
A data save information icon appears in the status display section while data is being saved.
Clicking the this icon displays a Data save dialog box. Clicking Quit save data aborts data
saving.
Data save information icon
Saving Display Data
Follow the procedure below to save unsaved display data stored in the internal memory to
the SD memory card.
Procedure
1
On the Operation tab, click Display save.
A Display save dialog box appears.
2
Click Save display data.
The display data is saved.
Resetting a Relative Timer
Follow the procedure below to reset and start a relative timer.
Procedure
1
On the Operation tab, click Timer reset.
The Timer reset dialog box appears.
2
Click the timer you want to reset, and click Reset.
The timer is reset.
Resetting a Match Time Timer
Follow the procedure below to reset a timer that has expired.
Procedure
1
On the Operation tab, click Reset Match Time Timer.
The Match time timer reset dialog box appears.
2
Click the match time timer you want to reset, and click Reset.
The match time timer is reset.
3.1 Using the Web Application to Change the GX/GP Settings, Monitor Data, and Control the GX/GP (Web server function)
