3-15
IM 04L51B01-01EN
Using Network Functions (Ethernet interface)
3
Changing the batch number, lot number, and batch comment
Follow the procedure below to change the batch number, lot number, and batch comment.
When the GX/GP is recording, you can enter only batch comments that have not been
entered yet.
Procedure
1
On the Operation tab, click Batch.
The Batch box appears.
2
Enter the batch number, lot number, and batch comment, and click Change.
The batch number, lot number, and batch comment are changed.
For the procedure to enter the batch number, lot number, and batch comment, see
page 1-148 in section 1.15, “Configuring the Batch Function”
To delete a batch comment, enter a space.
ViewingtheBatchtext
Follow the procedure below to view the batch text set on the GX/GP. You cannot change it.
Procedure
1
On the Operation tab, click Batch.
The Batch dialog box appears.
2
View the batch text, and click OK.
Changing the Time Using SNTP
Follow the procedure below to query the SNTP server for the time and adjust the GX/GP
time.
Procedure
1
On the Operation tab, click SNTP manual time adjustment.
The SNTP manual time adjustment dialog box appears.
2
Click ExecuteSNTPmanualtimeadjustment.
The GX/GP queries the SNTP server for the time.
Performing a Test Print
Follow the procedure below to perform a test print.
Procedure
1
On the Operation tab, click Test print.
A Test print dialog box appears.
2
Click Executeatestprint.
A test print is performed.
ExecutingaFileTransmissionTestontheFTPServer
Follow the procedure below to transfer a test file to the FTP server.
Procedure
1
On the Operation tab, click FTP test.
A FTP test dialog box appears.
2
Click ExecuteanFTPtesttotheprimary or ExecuteanFTPtesttothesecondary.
The GX/GP transfers a test le to the FTP server.
3.1 Using the Web Application to Change the GX/GP Settings, Monitor Data, and Control the GX/GP (Web server function)
