YOKOGAWA GX20 User Manual

1-62
IM 04L51B01-01EN
Alarm point mark
Setup Item Selectable Range or Options Default Value
Indicate on Scale Off, On On
Mark kind Alarm, Fixed Alarm
Alarm 1 color to Alarm 4 color
1
24 colors (red, green, blue, blue violet, brown,
orange, yellow-green, light blue, violet, gray,
lime, cyan, dark blue, yellow, light gray, purple,
black, pink, light brown, light green, dark gray,
olive, dark cyan, and spring green) and a user-
defined color (1 color)
—
1 Appears when the Mark kind is set to Fixed.
Indicate on Scale
Set this to On to display alarm point marks on the scale. Set this to Off to not display them.
This setting is shared with the bar graph display.
Mark kind
Options Description Mark Shape
Alarm Displayed normally in green. Displayed in the specified color
when an alarm occurs.
or
Fixed Displayed with a fixed color.
Alarm 1 color to Alarm 4 color
When Mark kind is set to Fixed, set the display colors of point marks for alarm levels 1 to 4.
Display characters of each value
1
Setup Item Selectable Range or Options Default Value
0
Character string (up to 8 characters,
A
a
#
1
)
—
1
Character string (up to 8 characters,
A
a
#
1
)
—
1 Appears when Calculation is set to Off.
0
Set the character string to display when the measured value is 0.
1
Set the character string to display when the measured value is 1.
For usage examples, see page 1-40 in section 1.2.3, “Setting the Display”.
1.3ConfiguringDIChannels(Digitalinputchannels)
