l External Dimensions
92
228
253
1600
354
Flow checker
Span gas valve
Zero gas valve
Gas outlet
F2-7E.ai
Zero gas cylinder (6 cylinder): E7050BA
Unit: mm
2.7 Other Equipments
2.7.1 Dust Filter for the Detector (K9471UA)

dust in recovery boilers and cement kilns.

l Standard specication
 
approximately perpendicular to the probe.)
Mesh: 30 microns
Material: Carborundum (Filter), SUS316 (JIS)
Weight: Approx. 0.2 kg
Part No. Description
K9471UA Filter
K9471UX Tool
Ø51
32
10
Carborundum filter (SiC)
Detector
Screw
Increasing of insertion length
F3-2E.ai
Attach the filter unit to the tip of
the detector by screwing it clockwise.
