  <2.Specications>
2-35
IM 11M12G01-02EN 1sh Edition : Mar. 25, 2021-00
l External Dimensions
Ø74
Primary
Secondary
88
Max. 210
max. 55
Approx. 122
Secondary
pressure
gauge
Panel (Horizontal mounting)
Panel (Vertical mounting)
G7003XF, G7004XF: Rc 1/4
K9473XK, K9473XG: 1/4NPT connector
airset.ai
A
22
ø15
2-ø2.2
+0.5
-0
2-ø6.5
40
2-ø6 screw depth 8
40
Horizontal
mounting
Vertical
mounting
Panel cut dimensions
View A
Unit : mm
2.7.7 Zero Gas Cylinder (G7001ZC)
The gas from this cylinder is used as the calibration zero gas and detector purge gas.
l Standard Specications
Capacity: 3.4 L
Filled pressure: 9.8 to 12 MPa G
Composition: 0.95 to 1.0 vol%O
2
in N
2
Weight: Approx. 6 kg

485
325
Φ140
Unit : mm
F2-13E.ai
