Canon iR6000 Service Manual

COPYRIGHT © 2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 4 IMAGE FORMATION SYSTEM
4-35 P
3.6.3 Others
COPIER>ADJUST>HV-SP>SP-N1 (Use it to adjust the output for the
first side of a double-side print or for a single-sided print of plain paper.)
COPIER>ADJUST>HV-SP>SP-N2 (Use it to adjust the output of the
second side of a double-sided print of plain paper.)
If the RAM on the DC controller PCB has been cleared, enter the value in-
dicated on the service label.
COPIER>AJDUST>HV-SP>HVT-SP (Enter the offset value for the sepa-
ration high-voltage output of the high-voltage unit.)
Enter the value indicated on the label attached to the new high-voltage unit
if the RAM on the DC controller PCB has been cleared or the high-voltage
unit has been replaced.
COPIER>ADJUST>HV-SP>D-HV-SP (Use it to enter the offset for the
separation high-voltage of the DC controller PCB.)
Enter the value indicated on the new DC controller PCB if the RAM on the
DC controller PCB has been cleared or the DC controller PCB has been re-
placed.
COPIER>OPTION>BODY>TR-SP-C1 (Use it to switch the transfer/
separation output value for pickup from the right deck.)
COPIER>OPTION>BODY>TR-SP-C2 (Use it to switch the transfer/
separation output value for pickup from the left deck.)
COPIER>OPTON>BODY>TR-SP-C3 (Use it to switch the transfer/sepa-
ration output value for pickup from the cassette 3.)
COPIER>OPTION>BODY>TR-SP-C4 (Use it to switch the transfer/
separation output for pickup from the cassette 4.)
COPIER>OPTION>BODY>TR-SP-MF (Use it to switch the transfer/
separation output for pickup from the manual feed tray.)
COPIER>OPTION>BODY>TR-SP-DK (Use it to switch the transfer/
separation output for pickup from the side paper deck.)
The transfer/separation output value is switched for each source of paper to
prevent various problems:
0: normal (default)
1: prevents double transfer
2: prevents separation faults
3: prevents transfer faults
Download Free Service Manual at http://printer1.blogspot.com

Canon iR6000 Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Functions	Print, Copy, Scan
Print Speed	60 ppm
Duplex Printing	Yes
Network Connectivity	Ethernet
Paper Sizes	A3, A4, B4, B5
Warm-Up Time	30 seconds
Multiple Copies	Up to 999
Magnification	25-400%
Copy Speed	60 ppm (A4)
