Canon iR6000 Service Manual

COPYRIGHT © 2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 3 STANDARDS AND ADJUSTMENTS
3-26 T
7.3 When Replacing the Main Controller PCB
1) Replace the main controller PCB.
2) Remove the counter memory PCB from the existing PCB, and mount it to the new PCB.
3) After assembling the machine, connect the power plug to the power outlet, and turn on
the main power switch.
7.4 When Replacing the HDD Unit
When replacing the HDD unit, be sure to keep the following in mind:
1. Take appropriate measures against static charges.
2. Keep the HDD unit protected from impact.
1) Replace the HDD unit.
2) After assembling the machine, connect the power plug to the power outlet.
3) Connect a PC to which the Service Support Tool has been installed.
4) Turn on the PC, and turn on the main power switch while holding down both ‘2’ and ‘8’
on the keypad.
5) Using the Service Support Tool, format the HDD unit and install the system software.
Download Free Service Manual at http://printer1.blogspot.com

Canon iR6000 Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Functions	Print, Copy, Scan
Print Speed	60 ppm
Duplex Printing	Yes
Network Connectivity	Ethernet
Paper Sizes	A3, A4, B4, B5
Warm-Up Time	30 seconds
Multiple Copies	Up to 999
Magnification	25-400%
Copy Speed	60 ppm (A4)
