Canon iR6000 Service Manual

COPYRIGHT © 2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 5 SERVICE MODE
5-33 T
3.4 FEEDER
Indicates the input/output ports of the ADF controller PCB.
<FEEDER (1/3)>
COPIER>I/O
Address
IO-P01
IO-P02
IO-P03
IO-P04
IO-P05
Bit
0
1
2
3
4
5
6
7
0
1
2
3
4
5
6
7
0
1
2
3
4
5
6
7
0
1
2
3
4
5
6
7
0
1
2
Notation
M2
M2
M1
M3
PI3
PI4
M1
M1
M1
M1
M2
CL1
SL1
VR1
S3
S2
S1
Description
feed motor drive clock
not used
feed motor clock LB
pickup motor clock LB
not used
delivery reversal motor clock LB
large/small identification sensor signal
A4R/LTRR identification sensor signal
pickup motor drive clock signal
pickup motor mode signal
pickup motor CW/CCW signal
pickup motor enable output
not used
feed motor enable output
pickup clutch drive signal
locking solenoid signal
serial communication
image leading edge signal
serial communication
EEPROM data output
EEPROM clock
EEPROM chip select
not used
not used
original width VR signal
post-separation sensor analog signal
read sensor analog signal
delivery reversal sensor analog signal
not used
not used
not used
not used
external WDT clock output
D/A data output
D/A clock output
Remarks
1: paper present (large)
1: A4R
1: enable
1: ON
1: attracted
transmission (TxD0)
reception (RxD0)
transmission (TxD1)
(SCK0)
(AN0)
(AN1)
(AN2)
(AN3)
