Canon iR6000 Service Manual

COPYRIGHT © 2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 5 PICK-UP/FEEDING SYSTEM
5-19 P
2.3.3 Markings on the Width Guide Rail
The width guide rail found inside the cassette is provided with paper size positioning
holes, given markings from A through M as shown below.
These markings can help determine whether the correct paper width is selected, as when
the user reports skew movement of paper (Note that this information is not disclosed to the
user).
Marking Paper name Remarks
A STMT-R
B A5-R
C B5-R
D KLGL-R
E GLTR-R
F G-LGL U3
G A4-R
H LGL/LTR-R
I FLSC U2
J B4/B5
K G-LTR U1
L 279.4×431.8mm U4
(11"×17") / LTR
M A3/A4
T05-203-02
Download Free Service Manual at http://printer1.blogspot.com

Canon iR6000 Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Functions	Print, Copy, Scan
Print Speed	60 ppm
Duplex Printing	Yes
Network Connectivity	Ethernet
Paper Sizes	A3, A4, B4, B5
Warm-Up Time	30 seconds
Multiple Copies	Up to 999
Magnification	25-400%
Copy Speed	60 ppm (A4)
