Canon iR6000 Service Manual

CANON iR5000/iR6000 REV.0 JULY 2000 2000 2000 2000 2000COPYRIGHT © 2000 CANON INC.
CHAPTER 4 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
4-14 T
3.14 The print has fixing faults
Copy paper
1) Is the paper of a type that has poor fixing performance (e.g., thick pa-
per)?
YES: Set ‘2’ (thick paper mode) in service mode:
COPIER>OPTION>BODY>FSPD-S.
Perform the following, and advise the user:
a. Set the source of paper (cassette, deck) to ‘Heavy’.
Additional Function>common settings>store paper type>source of
paper>‘Heavy’
b. Advise the user to always use the selected source of paper (after
depositing thick paper) whenever using thick paper.
2) Is the paper of a recommended type?
NO: Try using recommended paper. If the results are good, advise the
user to use recommended paper.
Fixing assembly
3) Does the problem occur vertically?
YES: Check the fixing roller for scratches and dirt.
NO: Check the fixing roller for nip.
Download Free Service Manual at http://printer1.blogspot.com

Canon iR6000 Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Functions	Print, Copy, Scan
Print Speed	60 ppm
Duplex Printing	Yes
Network Connectivity	Ethernet
Paper Sizes	A3, A4, B4, B5
Warm-Up Time	30 seconds
Multiple Copies	Up to 999
Magnification	25-400%
Copy Speed	60 ppm (A4)
