Page #255 background image
8-35
Cisco Customer Response Solutions Administration Guide, Release 4.1(1)
Chapter 8 Managing the Cisco CRS System
Managing System Parameters
Master Listener TCP Port TCP port used for communication between CVD and Cisco
Agent/Supervisor Desktop services.
Set one value for every cluster node. Set this port to a unique value
between 1 and 65635. (This setting should not conflict with other TCP
ports on the node.)
If you change this value, all CVD on all cluster nodes must be restarted.
Default: 994
SQL TCP Port
1
The TCP port on which the Cisco CRS SQL server instance listens for
database connections over TCP/IP network protocol.
Default: 4433
BARS Port TCP port for communicating between Backup and Restore and BRM.
Default: 996
Default Language System default language associated with new contacts for which no
language has been defined. This field specifies the last possible fallback
language when the system searches for resources such as prompts and
grammars.
Default: English (United States) [en_US]
Customizable Locales Use to specify a unique locale.
Default: (blank)
Default Currency Default currency, such as American dollars (USD), French Francs (FRF),
and so on.
The system uses the default currency for converting currency amounts in
a playable format when no currency designator is specified.
Default: American Dollar [USD]
Default TTS Provider Default TTS (Text-to-Speech) provider.
Default: By default, no TTS provider is configured. Select a provider
from the drop-down list to configure it as the default. The system uses
the default TTS provider to determine which provider to use if the TTS
request does not explicitly specify the provider to use.
Field Description
