● Remove the transmission bleeder tube.
● Remove the RH./LH. radiator hose from the RH.
crankcase.
● Face the LH. crankcase downward, and remove the RH.
crankcase from the LH. crankcase while tapping a few
places on the LH. crankcase with a plastic hammer.
NOTE
·Be careful not to distort the mating surface of the
crank case during removal.
● Remove the dowel pin and gasket.
CRANKSHAFT REMOVAL
● Remove the crankshaft from the RH. crankcase by
using a crankshaft remover.
● If the bearing is left on the RH. crankcase, use the
driver handle and the outer driver to remove it.
TOOLS : DRIVER
ATTACHMENT, 42 X 47 mm
● If the bearing is left on the crankshaft, use a bearing
puller to remove it.
TOOL : UNIVERSAL BEARING PULLER
NOTE
·After removing the crankshaft from the RH.
crankcase, replace the RH. crankshaft bearing with a
new one.
11-7
TRANSMISSION/CRANKSHAFT/CRANK CASE
