6-1
6. ENGINE REMOVAL
SERVICE INFORMATION
GENERAL SAFETY
NOTE
•Use a jack to remove or install the engine. Support the motorcycle with a jack firmly, taking precautions not to
damage the frame, engine, cable or harness.
•Attach tape to the frame to protect it during the engine removal or installation.
● The following works can be carried out without removing the engine from the vehicle body.
-TRANSMISSION (⇨SECTION 11)
-STARTING CLUTCH (⇨SECTION 8)
-OIL PUMP (⇨SECTION 2)
-A.C. GENERATOR (⇨SECTION 8)
-STARTER MOTOR (⇨SECTION 17)
-KICK STARTER/ CONTINUOUSLY VARIABLE TRANSMISSION (⇨SECTION 7)
-CYLINDER HEAD/ CYLINDER/ PISTON (⇨SECTION 9,10)
-EX. MUFFLER (⇨SECTION 4)
-CARBURETOR (⇨SECTION 5)
-REAR SWING ARM (⇨SECTION 13)
● Items to be worked after removing engine.
-CRANKSHAFT, CRANKSHAFT BEARING, CRANK CASE BEARING
● Engine oil capacity : 1.1ℓ- when disassembled.
TORQUE VALUES :
ENGINE HANGER BOLT (FRONT) : 2.7
㎏
f
·
m
(REAR) : 3.5
㎏
f
·
m
6
SERVICE INFORMATION
··········
6-1
ENGINE REMOVAL
················
6-2
