8-1
8. A.C GENERATOR / STARTER CLUTCH
SERVICE INFORMATION
GENERAL SAFETY
● This section describes the removal and assembling of the A.C generator.
● For information on A.C generator inspection, refer to the section 15.
● The charging system can be maintained without removing the engine.
SPECIFICATIONS
TORQUE VALUES
FLY WHEEL BOLT 5.5 kgf·m
STARTER CLUTCH LOCK NUT 9.5 kgf·m
RH. CRANKCASE COVER BOLT 1.1 kgf·m
TOOLS
SPECIAL SOCKET (12.7 x 28 x 120)
A.C.G ROTOR PULLER
8
SERVICE INFORMATION
····
8-1
SHROUD
··················
8-2
A.C GENERATOR
············
8-2
RH. CRANKCASE COVER
······
8-4
STARTER REDUCTION GEAR
··
8-5
STARTER CLUTCH
············
8-6
ITEM
STARTER DRIVEN GEAR
O.D
I.D
39.622 - 39.635
32.000 - 32.025
39.53
32.10
I.D
O.D
12.016 - 12.034
11.966 - 11.984
12.10
11.97
REDUCTION GEAR
REDUCTION GEAR SHAFT
STANDARD VALUE SERVICE LIMIT
Unit : mm
