12. FRONT WHEEL/FRONT FORK/STEERING
SERVICE INFORMATION
GENERAL SAFETY
CAUTION
● Keep oil or brake fluid off the brake disk and pad because the contaminated brake disk and pad reduces the braking
performance. If contaminated, replace the pad with a new one, and clean the disk.
● Use special tire levers and rim protectors to remove or assemble tires to protect the rim from being damaged.
● This section describes how to remove and maintain front wheels, front fork and steering system. For information on the
front brake system, refer to section 10.
● Place a jack underneath the engine to support the 2-wheeled vehicle.
SPECIFICATIONS
TORQUE VALUES
STEERING STEM NUT 6~8㎏f·m
STEERING TOP THREAD 0.15~0.25㎏f·m
BOTTOM BRIDE 7.0~8.0㎏f·m
FRONT BRAKE DISK BOLT 4.0~4.5㎏f·m
REAR BRAKE DISK BOLT 4.0~4.5㎏f·m
FRONT AXLE NUT 5.0~7.0㎏f·m
REAR AXLE NUT 5.0~7.0㎏f·m
FORK SETTING BOLT 1.5~2.5㎏f·m
FORK TUBE CAP BOLT 1.5~3.0㎏f·m
12
SERVICE INFORMATION
········
12-1
TROUBLESHOOTING
··········
12-2
STEERING HANDLE
··········
12-3
FRONT WHEEL
············
12-5
FRONT FORK
··············
12-10
STEERING STEM
············
12-15
FRONT AXLE DEFLECTION - 0.2mm
FRONT WHEEL WOBBLES
- 2.0mm
- 2.0mm
FRONT FORK PIPE DEFLECTION - 0.2mm
FRONT FORK OIL LEVEL 85cc -
FORK SPRING FREE LENGTH 266.3mm 258.3mm
REBOUND SPRING FREE LENGTH 21.2mm 20.6mm
RADICAL
AXIAL
ITEM STANDARD VALUE SERVICE LIMIT
