FRONT WHEEL INSPECTION
● Check the front axle for deflection. Place the front axle
on a V-block, and measure deflection with a dial gauge.
SERVICE LIMIT : 0.2mm
● Place the front wheel on an inspection stand. Slowly
turn the wheel, and check the rim for wobbles with a
dial gauge.
SERVICE LIMIT : Radial 2.0mm
Axial 2.0mm
Bearing Inspection
● Manually turn the bearing inner race, and replace if it
makes noise or is worn. Check if the bearing outer race
is accurately fitted into the wheel hub, and replace
worn ones.
NOTE
·Replace bearings in pairs (left and right set).
FRONT WHEEL DISASSEMBLY
● Remove the speedometer gear box, dust seal, and
speedometer gear retainer.
To Next Page
