4-1

4. EXTERNAL PARTS

SERVICE INFORMATION

NOTE

● This section describes external parts removal/installation.

● Do not apply unreasonable force when disassembling covers, to prevent possible damage.

● A muffler is hot. Do not service it immediately after the engine is stopped.

SERVICE INFORMATION

····

4-1

MAINTENANCE PRECEDURE

····

4-2

EXTERNAL PARTS

REMOVAL / INSTALLATION

··

4-3

MUFFLER

················

4-12
