● After removing the kick starter spindle from the return
spring, remove the kick starter spindle from the LH.
crankcase cover.
● Remove the kick starter return spring, kick starter bush
from the LH. crankcase cover.
KICK STARTER
INSPECTION
● Check the kick starter spindle for wear or damage.
● Check the return spring for defects or damage.
● Check the kick starter bush for damage.
● Check the kick starter driven gear for wear and damage.
● Check the friction spring for defects and damage.
7-4
LH. CRANKCASE COVER/KICK STARTER/CONTINUOUSLY VARIABLE TRANSMISSION
